Precision Linear Guide is the core guidance component for high-end precision transmission scenarios, specially designed for high-precision, low-friction and stable operation needs. Made of high-quality bearing steel through integral precision grinding process, it is compatible with 8-35mm guide width, 30-300mm stroke, with positioning accuracy of ±0.002mm, repeat positioning accuracy of ≤0.001mm and friction coefficient of ≤0.0015, enabling micron-level precise guidance..
Send Inquiry
Description
Send Inquiry

Details





Unlike ordinary linear guides, the Precision Linear Guide focuses on precision optimization: it adopts a high-precision ball circulation system with built-in ultra-precise balls, which reduces transmission resistance to the minimum, ensures smooth operation without jitter or stagnation, and has extremely small torque fluctuation during low-speed operation, perfectly matching the high-precision transmission needs of precision equipment.



In addition, the Precision Linear Guide is equipped with a fully enclosed dustproof sealing structure with a protection level of IP65, which can effectively block the intrusion of dust, impurities and water vapor, adapting to the clean operation environment of precision equipment. It also supports customized sizes, which can adjust the guide length, width and installation method according to equipment needs, and can be accurately adapted without complex debugging.



When ordering, provide the specifications, stroke, positioning accuracy requirements and matching equipment parameters of the Precision Linear Guide to ensure accurate adaptation to precision equipment; handle with care during installation, do a good job in coaxial calibration, and avoid guide deformation and precision damage caused by violent operation.



Main Features







High precision

Strict manufacturing process to ensure high straightness and parallelism, suitable for precision applications.




High rigidity

Able to withstand large loads, suitable for heavy loads and high rigidity requirements.




Low friction

Ball or roller design reduces friction and improves motion efficiency and response speed.




Long life

High quality materials and surface treatment prolong service life and reduce maintenance requirements.





Company Advantages





Leading R&D Design

Our proprietary R&D system and specialized team excel in structural optimization and performance upgrades. Core product metrics exceed industry averages, ensuring suitability for heavy-duty applications.

Exceptional Product Performance

Scientific solutions achieve balanced loading and error compensation, guaranteeing high-precision, stable operation to meet premium equipment demands.

Stringent Manufacturing Control

End-to-end quality assurance ensures product precision and consistency. Select components support high-precision interchangeability, reducing customer maintenance costs.

Full-Scene Adaptability

Deep market expertise enables customized solutions precisely covering machine tools, automation, semiconductors, and more.

Full-Cycle Efficient Service

End-to-end coverage-"pre-sales selection, in-process follow-up, post-sales maintenance"-ensures rapid response and stable equipment operation.

Driven by Continuous Innovation

Focused R&D investment proactively tracks industrial trends. Through technological breakthroughs and product iterations, we continuously strengthen our competitive edge in the industry.









Specification Parameters






Support Designation

Shaft Dimensions

Dimensions (mm)

Weight (kg)

E

h

B

H

T

F

X

Y

C

θ

S1

a1

a2

d1

SBR10

φ10

15

18

30

13.5

4

12.4

4.7

8.9

22/20

60°/80°

5

8.5

φ4.5

4.5

1.10

SBR12

φ12

15

20.46

30

15

4.5

15

6

9.8

25/22

60/80°

5

8.5

φ4.5

4.5

1.40

SBR13

中13

15

21

30

15

4.5

15

6

9.8

25/22

60°/80°

5

8.5

φ4.5

5.5

1.55

SBR16

φ16

20

25

40

17.8

5

18.5

8

11.7

30

60°/80°

6

9.5

φ5.5

5.5

2.56

SBR20

φ20

22.5

27

45

17.7

5

19

8

10

30

60°/50°

6.5

11

φ5.5

66

3.50

SBR25

φ25

27.5

33

55

21

6

21.5

8

12

35

60/50°

6.5

11

φ6.6

6.6

5.30

SBR30

φ30

30

37

60

22.8

7

26.5

10.3

13

40

60°/50°

8.5

14

φ6.6

9

7.38

SBR35

φ35

32.5

43

65

26.6

8

28

13

15.5

45

60/50°

8.5

14

φ9

9

9.68

SBR40

φ40

37.5

48

75

29.4

9

38

16

17

55

60°/50°

8.5

14

φ9

9

12.69

SBT50

φ50

47.5

62

95

38.8

11

45

20

21

70

60/50°

12.5

19

Φ11

11

20.46



Type

SBR12S

SB10

SB12

SB13

SB16

SB20

SB25

SB30

SB35

SB40

SB50

Standard length (L)

SBR16S
SBR20S
SBR25S
SBR30S

150
250
550
850

150
250
550
850

150
250
550
850

190
340
640
940

190
340
640
940

250
450
850
1250

450
850
1250
1450

460
660
860
1060

460
660
860
1060
1260

470
670
870
1070
1270

N

SBR35S

15

15

15

20

20

25

25

30

30

35

P

SBR40S

100

100

100

150

150

200

200

200

200

200

The maximum length

SBR50S

4000

4000

4000

6000

6000

6000

6000

6000

6000

600








Unit Designation

Dimensions


Weight


h

E

W

L

F

h1

0

B

C

S

L1

T

SBR10UU

15

18

36

32

24

6

80°

25

20

M5

10

7

65

SBR12UU

17

20.5

41

39

28

7.5

80°

28

26

M5

10

9

100|

SBR13UU

17

20

40

39

27.6

8.5

80°

28

26

M5

10

8

100|

SBR16UU

20

22.5

45

45

33

10

80°

32

30

M5

12

9

150

SBR20UU

23

24

48

50

39

10

60°

35

35

M6

12

11

200

SBR25UU

27

30

60

65

47

11.5

50°

40

40

M6

12

14

450

SBR30UU

33

35

70

70

56

14

50°

50

50

M8

18

15

630

SBR35UU

37

40

80

80

63

16

50°

55

55

M8

18

18

925

SBR40UU

42

45

90

90

72

19

50°

65

65

M10

20

20

1330

SBT50UU

53

60

120

110

92

23

50°

94

80

M10

20

25

3000

SBR16LUU

20

22.5

45

85

33

10

80°

32

60

M5

12

9

300

SBR20LUU

23

24

48

96

39

10

60°

35

70

M6

12

11

400

SBR25LUU

27

30

60

130

47

11.5

50°

40

100

M6

12

14

900

SBR30LUU

33

35

70

140

56

14

50°

50

110

M8

18

15

1260

SBR40LUU

42

45

90

175

72

19

50°

65

140

M10

20

20

2660



Product Display





3
4
6
2







Application Scenarios





3

Automated Production Lines: Serving as guide structures for material handling devices (e.g., automatic feeder slides) and assembly equipment (e.g., moving components of electronic component assemblers), ensuring precision and stability in material conveyance and component assembly.



Small Machine Tools: Compatible with desktop milling machines, lathes, and other compact machining equipment, used for workbench sliding supports or automatic tool changer guide rails, meeting precision requirements for small workpiece processing.



3D Printing Equipment: In FDM-type 3D printers, provides linear motion guidance for print heads (X/Y axes) and print platforms (Z axis), ensuring dimensional accuracy and surface quality of printed models.



Packaging Machinery: Used in actuators for semi-automatic sealing machines, labelers, and similar equipment. Examples include reciprocating motion guides for sealing mechanisms, guaranteeing consistency and efficiency in packaging operations.



Laser Processing Equipment: Provides smooth sliding guidance for laser heads in compact laser cutters and welders, enhancing edge smoothness and positional accuracy during laser cutting and welding.



Precision Inspection Instruments: Compatible with small-sized measuring instruments and surface roughness testers, guiding probe movements to ensure accurate scanning and measurement of test objects.







Installation Guide





Pre-Installation Preparation

  • Component Verification: Focus on confirming high-hardness shafts (bearing steel material, intact hard chrome plating, hardness HRC58-64, diameter conforming to G6 tolerance grade) and anti-skew aluminum rails (anodized finish, screw holes free of stripped threads with shaft hole alignment ≤0.02mm). Ensure smooth bearing sliding and compatibility of accessory specifications.
  • Environment and Tools: Select a clean, dust-free, non-corrosive installation environment. The mounting surface must be level; use thin shims to compensate for unevenness. Prepare necessary tools, including measuring instruments such as micrometers, hardness testers, thread gauges, and spirit levels, along with a torque wrench capable of setting torque according to bolt specifications.



 Key Installation Procedures

  • Shaft-to-Aluminum Rail Assembly: Insert high-hardness shaft into aluminum rail groove. Calibrate parallelism using dial indicator to ≤0.01mm/m. Tighten bolts diagonally in stages to preset torque. After bearing sleeve shaft slides, measure bearing-to-rail clearance ≤0.02mm to verify anti-skew function.
  • Fixed Assembly of Complete Unit: Use a unit with shaft tolerance near G6 median value and high bolt hole precision as the reference. Ensure the clearance between the aluminum rail and the equipment is ≤0.01mm. Adjust the unit's levelness to ≤±0.02mm/m and straightness to ≤0.03mm (over full length) before tightening the bolts. For multi-unit installations: Calibrate parallelism between driven shafts and reference shafts ≤0.05mm/m using 0.005mm/m precision straight edge blocks. Ensure bolt hole centerline alignment ≤0.03mm.
  • Bearing and Load Installation:Clean shafts and bearings. Install bearings onto shafts in correct orientation, confirming smooth sliding without resistance. Load installation must ensure the load center coincides with the bearing center. Eccentric loads must not exceed 25% of the bearing's rated dynamic load. Fasten bolts symmetrically with torque deviation ≤1 N·m.



Acceptance and Maintenance Specifications

  • Acceptance Criteria: Shaft diameter maintains G6 tolerance, load sliding straightness ≤0.04 mm/m, operating noise ≤55 dB; All bolts must be secure with no loosening, aluminum rail thread holes must be undamaged, and after 24 hours of static placement, precision deviation ≤0.01mm is considered acceptable.​
  • Routine Maintenance: Apply specialized grease to shafts and affix protective film to aluminum rails. Re-inspect precision and bolt torque after initial 100 hours of operation. Subsequently, perform cleaning and lubricant replenishment every 2 weeks based on an 8-hour daily operating frequency.​





FAQ





Q: What is your co-operation process?

A: Demand docking: Reply to customer's demand within 2 hours, provide selection suggestions;
Sampling confirmation: 7 days delivery of samples, support free design optimisation;
Batch production: The production process is transparent, customers can view the progress through the cloud.

Q: Can you provide OEM service for linear guide?

A: Yes, we focus on the customised production of linear guide, support the whole process of OEM service from parameter design to batch delivery.

Q: How about the packaging?

A: Plastic bag + shockproof foam boxed, or wooden box package, support custom packaging (such as waterproof film, rust treatment). We provide three layers of protection to ensure that there is no damage during transport, and the international transport meets DHL/FedEx standards.
