High-Precision Ball Screws: Core Transmission Solutions for CNC/Automation

Lishui Jiesheng Transmission was established in 2020, specializing in the R&D, production, and global sales of high-precision linear transmission systems. Its core product, the high-precision ball screw, addresses the pain points of low transmission accuracy in CNC machine tools and automated equipment, serving as a key component for enhancing equipment efficiency.

VR Factory Tour

Customized Solutions

Supports custom lead screws and optimizes production line transmission solutions to meet specific requirements.

Prompt After-Sales Response

24-hour response time with remote technical guidance + rapid spare parts delivery to minimize downtime.

One-Stop Compatibility

Synchronized supply of matching accessories eliminates the need for multiple suppliers, reducing coordination costs.

Full Technical Support

Includes installation guidance, commissioning assistance, and operational training to lower usage barriers.

SFU Ball Screws
SFU series ball screws are constructed with precision-ground raceways and imported alloy steel. They deliver good transmission accuracy of up to ±0.015mm/300mm, long service life and low friction,
High Precision Ball Screw
This high-precision ball screw can be optimized and customized according to customers' actual needs. It is made of high-quality alloy steel, with a lead accuracy of GB/T 17587.3 Grade C5-C7, suitable
Micro Ball Screw
This micro ball screw can be precisely customized according to customers' needs, made of high-quality high-strength alloy steel, with a lead accuracy of GB/T 17587.3 Grade C5-C7, suitable for lead
Precision Ground Ball Screw
This micro precision ground ball screw is made of high-quality high-strength alloy base material, integrally formed and processed by precision grinding. It is small in size, compact in structure,
CNC Machine Lead Screw
This CNC machine tool screw is designed for precision transmission of CNC machine tools. Made of high-strength alloy base material, it features C5 grade lead accuracy and concentricity error
Ball Screw Rod Assembly
This ball screw assembly is customized for precision transmission equipment. Manufactured with high-precision grinding technology, it achieves C5 grade lead accuracy with excellent concentricity and
Stainless Steel Lead Screw
This stainless steel lead screw is made of high-quality 304/316 stainless steel base material, processed by precision grinding, with lead accuracy of C5 grade and concentricity error ≤0.005mm. It has

Ball Screws Product Description

Ball screws are core transmission components in industrial automation, offering high precision, low backlash, high rigidity, and exceptional durability. Compatible with mainstream mounting specifications, they adapt to various equipment such as CNC machine tools, industrial robots, and smart production lines, enabling precise conversion from rotary to linear motion. This enhances equipment positioning accuracy and production efficiency.

Why Choose Us

High Precision

Utilizing precision grinding technology, it features minimal transmission clearance and accurate positioning (with micron-level tolerances), meeting the demands of high-precision equipment such as machine tools and robots.

Durable Performance

Crafted from premium bearing steel and enhanced through multiple strengthening processes like quenching, it offers exceptional wear resistance, vibration damping, and extended service life, reducing the hassle and cost of frequent replacements.

Versatile Compatibility

Comprehensive coverage of standard models for direct compatibility across machine tools, new energy, automation, and other industries. Custom dimensions and leads available for specialized applications.

Service Excellence

Free engineer-guided selection + installation support. 12-month warranty + 24-hour service response. Standard models shipped from stock; custom orders delivered expeditiously.

Advantages of Ball Screws

Highly Efficient

Ball screws are more efficient than other types of screws, boasting 90% efficiency in comparison to a lead screw’s 20-80%. This means that ball screws are able to convert more of their rotary motion to linear motion more quickly than other types of screws.

Accurate

Ball screws are also known for their accuracy. They enable high-precision positioning due to their low return clearance and high rigidity.

Lessen Friction

The ball bearings of a ball screw serve to reduce friction as the nut moves along the shaft of the screw. This results in less wear to the device in addition to a longer lifespan.

Stability

Ball screws can handle larger loads without sacrificing stability, making them reliable in demanding environments.

Durability

Hardened steel balls ensure a long lifespan and reduced wear over time.

Specification

Product Name	Ball Screws
Material	Alloy steel, chrome-molybdenum alloy steel, stainless steel, bearing steel.
Length	Length can be customised according to customer requirements.
Applications	Machine tools, automation equipment, aerospace, military, semiconductor manufacturing, medical equipment and precision measuring instruments.
Services	We can manufacture products according to drawings or samples, and support sending samples.
Accuracy Grade	C3/C5/C7
Packaging	Plastic bag in box or wooden case.
Delivery time	According to customer requirements.

Application of Ball Screws

Machine tools
One of the main examples that uses ball screws for their high-tech characteristics is machine tools. Balls screws are used to provide linear motion that is required in many different types of machines including lathes, milling machines and other computer numerical control (CNC) machines.

Robotics
Ball screws are also used in various types of robotic applications due to their smooth and accurate characteristics. You can find them in many robotic arms and legs, giving these unique technological advancements the ability to move.

Aerospace systems
In many aircraft control systems, you can find ball screws due to their accuracy and low friction tendencies. Ball screws can also be found in many other aerospace applications.

Medical equipment
Ball screws can be found in various medical devices due to their increased reliability in comparison to other screw options. Specifically, the balls screws can be found in imaging tools and surgical robots.

Automotive
The different types of ball screws can be found in many different processes throughout the automotive industry. These components are used in automotive manufacturing, as well as assembly lines and unique robotic systems.

Industrial automation
Conveyor systems, packaging machines, and 3D printers use ball screws for consistent linear motion, handling high-speed or heavy-duty cycles with minimal friction.

Semiconductor manufacturing
Ball screws position wafers in chip-making equipment, offering nanoscale accuracy—vital for etching circuits in cleanroom settings.

Applications in the field of automation

Applications in the medical field

Applications in the Logistics Sector

Components of Ball Screws

01/

Threaded shaft: The threaded shaft is the core component of the ball screw. It is made of high-strength steel and has a precise thread profile that the ball bearings move along.

02/

Nut: The nut is the housing for the ball bearings. It is typically made of steel and is designed to minimize friction between the ball bearings and the threaded shaft.

03/

Ball bearings: The ball bearings are what enable the nut to move along the threaded shaft. They are typically made of steel or ceramic and are designed to minimize friction and wear.

04/

End supports: The end supports are used to hold the ball screw in place and support the load. They are typically made of cast iron or steel and are designed to minimize deflection and vibration.

05/

Recirculation system: The recirculation system allows the bearings to move continuously between the grooves on the screw.

06/

Seals: Seals shield the ball bearings and the recirculation system from external contaminants such as dust. This helps to keep the bearings lubricated, reducing wear and friction.

Installation method and usage precautions of ball screws

Installation method

One end is fixed, and the other is supported. This is the most common installation method, suitable for medium-speed to high-speed rotation, and the accuracy level can reach medium precision and high precision;

Fixed at both ends, only suitable for medium-speed rotation and with high precision;

One end is fixed, and the other is free, suitable for low-speed rotation and medium precision.

Precautions for Using Ball Screw

When installing: Be careful not to damage the tooth surface of the screw; after the screw is purchased, the nut and screw are together, so when installing, pay special attention. First, at both ends. Tie a tie or install a limit block. Do not separate the nut and screw. Once separated, it will be challenging to install them. If it is accidentally separated, do not force yourself to install it.

Lubrication: There is metal friction between the ball and the screw, so lubricating oil or grease must be added between the two. Otherwise, the service life will be reduced; the general adding methods include manual and automatic refueling. Manual refueling is performed regularly by workers. Oil filling and automatic oiling require an automatic oiling system;

Dustproof: Ball screws are the same as rolling bearings. When mixed with debris, water, or cutting fluid, the wear will increase, sometimes leading to damage. When designing, pay attention to the dustproof ness of the screw;

When the eccentric load phenomenon occurs:It will directly affect the life and noise of the screw and is accompanied by a rough operating feel. If the smoothness of the screw is different when it is unloaded and after assembly, in addition to paying attention to the accuracy of the screw itself, most of them is the phenomenon of eccentric load caused by poor combination accuracy.

FAQ

Q: I have special requirements for the size and structure of ball screw rod assembly, can I customise it?

A: Of course! We have a professional customisation team, as long as you provide detailed design drawings or specific needs, such as special screw rod diameter, guide, non-standard shape of the nut, mounting methods, etc., we can customize for you to create your own ball screw rod assembly.

Q: I have strict requirements on product quality, how do you guarantee the quality of your ball screw rod assembly?

A: We control from the source, select high-quality raw materials, the whole production process through a number of high-precision testing procedures, the finished product will also be sampling. We can provide test reports to ensure the quality is excellent.

Q: Will the screws be damaged during international transport? Is the packaging reliable?

A: We use professional multi-layer protective packaging, the interior is filled with high-density foam, and the exterior is reinforced wooden box. Past orders sent to all over the world rarely appear transport damage. If there is any problem, we will be responsible to the end.

Q: I want to print my shop logo on the screw, can it be customised?

A: Customisation is possible. We provide personalised service, in addition to printing the logo, you have special requirements for the size and material of the screw, we can communicate to achieve, to create exclusive products for you.

Q: If I buy your high precision ball screws, will there be any technical support after that? Can help to solve the installation and commissioning problems?

A: Of course! We provide a full range of after-sales technical support, installation and commissioning stage, you can guide you through the video operation of the product in use if there is a problem, our after-sales team 24-hour response, the first time for you to troubleshooting, provide solutions.

Q: Can we provide samples for testing first?

A: No problem! You only need to provide detailed requirements, we immediately arrange for sample production and delivery, but do not bear the freight. The sample comes with a complete test report, your test period, our technicians online, ready to answer questions, to assist you to complete the test evaluation, satisfied with the bulk purchase.

Q: Do you provide product testing report?

A: Of course! Before each batch of products leave the factory, they are strictly tested for precision, load, life and so on. Detailed quality inspection report will be attached when delivered.

Q: What is the durability of Grinding Ball Screws?

A: We use high-grade alloy steel, special heat treatment to enhance the hardness and toughness. Grinding process makes the surface smooth and wear-resistant, under normal working conditions, the service life is far more than ordinary screws, strong stability.

As one of the leading ball screws manufacturers and suppliers in China, we warmly welcome you to wholesale customized ball screws made in China here from our factory. For quotation, contact us now.
